產品詳情
產品參數
|
Contact Form 觸點形式 |
Form A | ||||||||||||
|
Switching Power(Max.) ?最大開關功率 |
10 | W | |||||||||||
|
Switching Voltage DC (Max.) ?最大開關電壓 |
170 | V | |||||||||||
|
Switching Current (Max.) ?最大開關電路 |
0.5 | A | |||||||||||
|
Carry Current DC (Max.) ?最大負載電流 |
0.5 | A | |||||||||||
|
Breakdown Voltage (Min.) ?最小擊穿電壓 |
210 | V | |||||||||||
|
Contact Resistance (Initial Max.) ?最大初始接觸電阻 |
0.15 | Ω | |||||||||||
|
Contact Capacitance (Max.) ?最大接觸電容 |
0.35 | pF | |||||||||||
|
Insulation Resistance (Min.) ?最小絕緣電阻 |
1012 | Ω | |||||||||||
| Operating Temperature Range 工作溫度范圍 | -55℃ ~ 125℃ | ℃ | |||||||||||
