產品詳情
產品參數(shù)
|
Contact Form 觸點形式 |
Form C | ||||||||||||
|
Switching Power(Max.) ?最大開關功率 |
60 | W | |||||||||||
|
Switching Voltage DC (Max.) ?最大開關電壓 |
230 | V | |||||||||||
|
Switching Current (Max.) ?最大開關電路 |
1 | A | |||||||||||
|
Carry Current DC (Max.) ?最大負載電流 |
2 | A | |||||||||||
|
Breakdown Voltage (Min.) ?最小擊穿電壓 |
400 | V | |||||||||||
|
Contact Resistance (Initial Max.) ?最大初始接觸電阻 |
0.1 | Ω | |||||||||||
|
Contact Capacitance (Max.) ?最大接觸電容 |
1 | pF | |||||||||||
|
Insulation Resistance (Min.) ?最小絕緣電阻 |
109 | Ω | |||||||||||
| Operating Temperature Range 工作溫度范圍 | -40℃ ~ 125℃ | ℃ | |||||||||||
