0755-8253 2401
STUMPBACK
Product Details
Product Parameters
| Contact Form | Form? A | ||||||||||||
| Switching Power (Max.) Maximum switching power | 40 | IN | |||||||||||
| Switching Voltage DC (Max.) Maximum switching voltage | 250 | In | |||||||||||
| Switching Current (Max.) Maximum switching current | 1 | A | |||||||||||
| Carry Current DC (Max.) Maximum load current | 3 | A | |||||||||||
| Breakdown Voltage (Min.) Minimum breakdown voltage | 300 | In | |||||||||||
| Contact Resistance (Initial Max.) Maximum initial contact resistance | 0.09 | Oh | |||||||||||
| Contact Capacitance (Max.) Maximum contact capacitance | 0.2 | pF | |||||||||||
| Insulation Resistance (Min.) Minimum insulation resistance | 1012 | Oh | |||||||||||
| Operating Temperature Range | -55℃ ~ 125℃ | ℃ | |||||||||||
